Color

Red

Compatibility

Linux, PC

Data Transfer Rate

10 Gbps

Interface Type

PCI Express

Type

Wired

General

Device Type

Network adapter

Form Factor

Plug-in card

Interface (Bus) Type

PCI Express 2.0 x8

PCI Specification Revision

PCIe 2.0

Networking

Ports

10Gb Ethernet x 2

Connectivity Technology

Wired

Data Link Protocol

10 Gigabit Ethernet

Data Transfer Rate

10 Gbps

Remote Management Protocol

SNMP

Status Indicators

Port status, link/activity

Features

Jumbo Frames support, teaming support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS)

Compliant Standards

IEEE 802.3, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3p, IEEE 802.3ap, IEEE 802.1au

Processor / Memory

Processor

1 x Broadcom BCM57810S

RAM

256 MB

Expansion / Connectivity

Interfaces

2 x 10Gb Ethernet

Compatible Slots

1 x FlexibleLOM

Miscellaneous

Compliant Standards

VCCI Class B ITE, EN 61000-3-2, EN55022, EN 61000-3-3, FCC Part 15 B, WEEE, RoHS

Software / System Requirements

OS Required

SunSoft Solaris 10, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x

Environmental Parameters

Min Operating Temperature

32 °F

Max Operating Temperature

131 °F

Humidity Range Operating

10 - 90% (non-condensing)

Compatibility Information

Designed For

HPE ProLiant DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Special Server, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL388p Gen8 Base, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, SL250s Gen8 2U Left Half Width Tray, SL250s Gen8 2U PCIe Gen3 Left Tray, SL250s Gen8 2U Right Half Width Tray, SL250s Gen8 Base 2U Left Half Width Tray, SL250s Gen8 Base 2U Left Tray Server, SL250s Gen8 Base 2U Right Half Width Tray, SL250s Gen8 Base 2U Right Tray Server, SL270s Gen8 1U Left Half Width Tray, SL270s Gen8 1U Right Half Width Tray, SL270s Gen8 Base 4U Left Half Width Tray, SL270s Gen8 Base 4U Right Half Width Tray, SL270s Gen8 SE 4U Left Tray, SL270s Gen8 SE 4U Right Tray
