JW751A HPE Aruba 7220 Wireless LAN Controller
Item No.
Free eBay listing template designed by dewiso.com
Aruba 7220 (RW) 4p 10GBase-X (SFP+) 2p Dual Pers (10/100/1000BASE-T or SFP) Controller
The Aruba 7200 Series Mobility Controllers is the next-generation networking platform, optimized for mobile application delivery to ensure the best mobility experience over Wi-Fi. With a new central processor that employs up to eight cores with four threads each, it's like having a total of 32 virtual CPUs. As a result, the 7200 series supports up to 32,768 mobile devices and performs stateful firewall policy enforcement at 100 Gbps – plenty of capacity and speed for BYOD and 802.11ac devices.
|
Device Type |
Network management device |
|
Height (Rack Units) |
1U |
|
Built-in Devices |
Status LCD |
|
Width |
17.5 in |
|
Depth |
17.5 in |
|
Height |
1.7 in |
|
Weight |
16.42 lbs |
|
Localization |
Rest of World |
|
Form Factor |
External |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
|
Network / Transport Protocol |
IPSec |
|
Performance |
Firewall throughput: 40 Gbps |
|
Capacity |
Maximum number of access points: 1024 ¦ Concurrent devices: 24576 ¦ Virtual interfaces (VLANs): 4094 ¦ Concurrent GRE tunnels: 163 ... |
|
Status Indicators |
Status, link/activity |
|
Features |
Layer 3 switching, VPN support, IPv6 support, IPv4 support, Adaptive Radio Management (ARM), AppRF technology |
|
Compliant Standards |
IEEE 802.11ac |
|
Interfaces |
4 x 10GBase-X - SFP+ ¦ 2 x 1000Base-T ¦ 1 x USB 2.0 ¦ 1 x console - RJ-45 ¦ 1 x mini-USB |
|
Power Device |
Internal power supply - hot-plug |
|
Installed Qty |
1 |
|
Max Supported Qty |
2 |
|
Power Redundancy |
Yes |
|
Voltage Required |
AC 120/230 V (50/60 Hz) |
|
Power Consumption Operational |
125 Watt |
|
Power Provided |
350 Watt |
|
Service & Support |
Limited warranty - parts and labor - 1 year ¦ New releases update - 90 days |
|
Min Operating Temperature |
32 °F |
|
Max Operating Temperature |
104 °F |
|
Humidity Range Operating |
5 - 95% (non-condensing) |
|
Product Description |
HPE Aruba 7220 (RW) Controller - network management device |
|
Power |
AC 120/230 V (50/60 Hz) |
|
Dimensions (WxDxH) |
17.5 in x 17.5 in x 1.7 in |
