Features
VPN Support, With Antivirus Software
General
Device Type
Security appliance
Height (Rack Units)
2U
Width
17.2 in
Depth
21.8 in
Height
3.5 in
Weight
32.41 lbs
Processor / Memory / Storage
Processors Installed
Fortinet FortiASIC CP8
Hard Drive
SSD 120 GB
Networking
Form Factor
External
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Network / Transport Protocol
IPSec
Performance
Firewall throughput (1518-byte packet size): 72 Gbps Firewall throughput (512-byte packet size): 72 Gbps Firewall throughput (64-byte packet size): 52 Gbps IPS throughput: 11 Gbps IPS throughput (512-byte packet size): 48 Gbps Proxy-based antivirus throughput: 3.5 Gbps Flow-based antivirus throughput: 9.5 Gbps Firewall latency (64-byte UDP): 6 µs Firewall throughput: 78 Mpps VPN throughput (512-bit IPSec): 48 Gbps VPN throughput (SSL): 3.6 Gbps
Capacity
Concurrent sessions: 11000000 New sessions per second: 240000 Firewall policies: 100000 Gateway to gateway IPSec VPN Tunnels: 10000 Client to gateway IPSec VPN tunnels: 50000 Virtual domains: 250 Number of FortiAP devices: 4096 User licenses: unlimited Number of FortiToken devices: 5000 Number of FortiClient devices: 8000
Features
Firewall protection, VPN support, content filtering, IPv6 support, VPN passthrough, antivirus analysis, High Availability, Intrusion Prevention System (IPS), IPv4 support
Encryption Algorithm
SSL
Expansion / Connectivity
Interfaces
16 x 1000Base-T - RJ-45 16 x Ethernet 1000 - SFP (mini-GBIC) 4 x 1Gb Ethernet/10Gb Ethernet - SFP+ 2 x 1000Base-T (management) - RJ-45 1 x USB 2.0 - Type A 1 x USB 2.0 - Type B 1 x console - RJ-45
Miscellaneous
Compliant Standards
UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Intrusion Detection, ICSA Antivirus, CB, FCC Part 15 A
Power
Power Device
Internal power supply - hot-plug
Installed Qty
2
Max Supported Qty
2
Power Redundancy
Yes
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
332 Watt
Software / System Requirements
OS Provided
FortiOS 5
Environmental Parameters
Min Operating Temperature
32 °F
Max Operating Temperature
104 °F
Humidity Range Operating
20 - 90% (non-condensing)
