The HPE MSR4000 Router Series deliver high-performance large branch routing with up to 36 Mpps in a cost-optimized form factor. Featuring integrated routing, switching, security, VPN, and SIP with no additional licensing, you can boost your service delivery while simplifying the management of your corporate WAN. With the Open Application Platform module, the MSR4000 Router Series offers a wide range of virtualized applications.

Authentication Method

Extensible Authentication Protocol (Eap), Radius, Secure Shell V.2 (SSH2), Tacacs+

Capacity

512 GB

Color

Black

Compliant Standards

Fcc, Iec 60950-1, Ieee 802.1q, Ul 60950-1

Connectivity Technology

Wired Connectivity

General

Device Type

Modular expansion base

Enclosure Type

Desktop, rack-mountable - modular - 4U

Connectivity Technology

Wired

Network / Transport Protocol

TCP/IP, UDP/IP, L2TP, RSVP, NTP, IPSec, ARP, DHCP

Routing Protocol

OSPF, RIP, BGP-4, IS-IS, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng, MLD, MPLS, Bidirectional Forwarding Detection (BFD)

Remote Management Protocol

SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, CLI

Encryption Algorithm

MD5, SSL, TLS

Authentication Method

RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)

Features

Firewall protection, DHCP support, NAT support, VPN support, ARP support, MPLS support, IGMP snooping, Syslog support, port mirroring, IPv6 support, Weighted Fair Queuing (WFQ), Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Committed Access Rate (CAR), MLD snooping, Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), Dynamic Virtual Private Network (DVPN), Network Quality Analyzer (NQA), Multicast Source Discovery Protocol (MSDP), Multicast Border Gateway Protocol (MBGP)

Compliant Standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, CISPR 22 Class A, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC Part 68, EMC, ICES-003 Class A, CS-03, EN 61000-4-5, EN 61000-4-11, RoHS, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, EN 60825-1, AS/NZS 60950, ANSI C63.4-2003, EN 60825-2, CAN/CSA C22.2 No. 60950-1-03, EN 61000-3-2:2006, EN 300 386

Expansion / Connectivity

Interfaces

Management: 1 x RJ-45 Management: 1 x RS-232C/USB

Expansion Slots

3 (total) / 3 (free) x expansion slot 6 (total) / 6 (free) x High-performance Multifunction Interface Module (HMIM)

Installed Modules Qty (Max)

0 (installed) / 9 (max)

Power

Power Device

Internal power supply (not installed)

Installed Qty

4 (max)

Voltage Required

AC 120/230 V (50/60 Hz)

Miscellaneous

Rack Mounting Kit

Included

MTBF

178.66 years

Dimensions & Weight

Width

17.3 in

Depth

18.9 in

Height

6.9 in

Weight

45.52 lbs
